Standard Plugs - Open (Brass Wingnuts)
Price
$8.50 - $40.85- Product Description
- Specifications
- Media Resources
- Replacement Parts
Product Description
Open plugs have a hollow center stem that allows for the introduction of air or water pressure into the system you are testing. These versatile plugs feature durable brass hardware, straight-sided rubber, and a brass wingnut. National pipe threaded tops on the open stem plugs make them easy to set up for pressure testing, clearing blocked lines, or blowing out lines for winterization. The plug top is a combination 1/8" pipe thread and 3/8" hose barb. When using with the Anderson Water & Air Pressure Testers (PT14 & PT16) a quick connect fitting will need to be added to the stem (CL18 or CPH18).
Brass wingnuts are the strongest option, but they require maintenance to avoid corrosion and locking up. Keep in mind that most oil-based lubricants will damage the rubber of the plug, so we recommend using a silicone lubricant.
Straight sided rubber is the best choice for accurate, safe pressure testing in swimming pool plumbing lines, but it’s important to choose the correct sized plug. We recommend choosing a plug size that is about 1/8” smaller than the inside diameter of the pipe opening you are plugging off. The measurement listed for each size is the actual diameter of the unexpanded rubber. Additionally, recommended pipe applications for each size can be seen under “Specifications” once you select a size from the drop-down menu.
Brass wingnuts are the strongest option, but they require maintenance to avoid corrosion and locking up. Keep in mind that most oil-based lubricants will damage the rubber of the plug, so we recommend using a silicone lubricant.
Straight sided rubber is the best choice for accurate, safe pressure testing in swimming pool plumbing lines, but it’s important to choose the correct sized plug. We recommend choosing a plug size that is about 1/8” smaller than the inside diameter of the pipe opening you are plugging off. The measurement listed for each size is the actual diameter of the unexpanded rubber. Additionally, recommended pipe applications for each size can be seen under “Specifications” once you select a size from the drop-down menu.
Specifications
Air Delivery | |
Batteries | |
Blower Fitting | |
Bypass Diameter | |
Case Size | |
Chuck Size | |
Color | |
Cure Time | |
Electrical | |
Expansion | |
Extension Length | |
Filter Types | |
Frequency Range | |
Gain | |
Proper Inlation Pressure | |
Input Current | |
Length | |
Made By | |
Made In | |
Maximum Depth | |
Maximum Diameter | |
Minimum Diameter | |
Minimum Temperature | |
Mixer Tubes | |
Motor | |
Opening Connection | |
Pipe Application | |
Regulator | |
Shipping Weight | |
Sticker Color | |
Unlabeled Spec 1 | |
Unlabeled Spec 2 | |
Unlabeled Spec 3 | |
Vacuum Fitting | |
Wireless Connection |
